| Specification | Value |
|---|---|
| Material | Steel |
| Adjustment Type | Adjustable Compression Damping / Adjustable Rebound Damping |
| Bore Size | 36.00 mm |
| Color/Finish | Chrome / Yellow |
| Linear Spring Rate | 120.00 lb/in |
| Product Name | Shock Absorber |
| Units | Each |
| Damping Method | Gas Charged |
| Extended Length | 9.61" |
| Riding Style | Street |
| Model | STX |
| Mounting Position | Rear |
| Reservoir Location | Mounted External Reservoir |
| Type | Coilover Monotube |
- Adjustable Rebound and Compression damping
- Monotube Shock with External Piggyback Reservoir
- High Pressure Nitrogen Gas Charged
- STX Single Tube design
- 36 mm Piston Diameter
- Adjustable Preload w/ tool
- Top Level Comfort, Rideability and Performance
- Hard Anodized - Precision CNC-Machined Components
- Low-friction Shaft / Seal Head design
- Fully Serviceable and Repairable
- For Honda Grom rider over 80 kg/176 lb (If under 80kg/176 lb see HO 424).
FITMENTS
| Year | Make | Model |
|---|---|---|
| 2020, 2022, 2023 | Honda | Grom 125 ABS |
| 2020, 2022, 2023 | Honda | Grom 125 |
- Color:
- Chrome
