| Specification | Value |
|---|---|
| Color/Finish | Gray / Black |
| Material | Steel |
| Spring Type | Single Progressive Rate |
| Damping Method | Gas Charged |
| Progressive Spring Rate | 120.00 lb/in - 170.00 lb/in / 2.15 kg/mm - 3.00 kg/mm |
| Mounting Position | Rear |
| Model | 512 Series |
| Reservoir Location | Internal |
| Riding Style | ATV |
| Type | Coilover Twin-Tube |
| Adjustment Type | Adjustable Rebound Damping |
| Extended Length | 15.50" |
| Product Name | Shock Absorber |
| Units | Pair |
- Increase ground clearance and wheel travel 1"-2" on most models
- Rugged double-steel-wall construction
- Progressive rate springs for comfortable ride and improved load-carrying capacity
- Five-position spring pre-load adjustment for varying loads
- Gas charged for fade-free operation
- Durable fabric Shock Sox are included to protect shocks from rock, sand and mud damage
- Shock Sox are easily removable with hook-and-loop fasteners for cleaning and adjustments
- Not compatible with lift kits
FITMENTS
| Year | Make | Model |
|---|---|---|
| 1998-2001 | Honda | TRX450FE FourTrax Foreman ES |
| 2002-2004 | Honda | TRX450FM FourTrax Foreman S |
| 1998-2001 | Honda | TRX450S Foreman 4x4 |
- Color:
- Gray
