| Specification | Value |
|---|---|
| Units | Kit |
| Displacement | 400 cc |
| Riding Style | Street / Off-Road |
| Product Name | Top End Piston Kit |
| Style | Forged Replica |
| Compression Ratio | 11.3:1 |
| Cylinder Diameter | 90.00 mm |
| Engine Type | 4-Stroke |
| Piston Diameter | 89.96 mm |
| Piston Material | Forged 2618 Aluminum |
| Skirt Coating | Molybdenum Disulphite |
- The piston is heat-treated with a T-5 hardening and tempering cycle
- The piston skirt is coated with high-tech Molybdenum Disulphite to allow faster break in time and increased piston life
- Forged piston kit is forged from 2618 aluminum
- Forged replica piston is a forged OEM replacement
- Top-end piston kit includes piston, rings, pins, circlips, top-end gaskets and cam chain
FITMENTS
| Year | Make | Model |
|---|---|---|
| 2000-2022 | Suzuki | DR-Z400S |
| 2005-2022 | Suzuki | DR-Z400SM |
| 2000-2007 | Suzuki | DR-Z400E |
| 2000-2007 | Suzuki | DR-Z400 |
| 2003-2004 | Kawasaki | KLX400R |
